DTMOS IV: Gen-4 Super-Junction 600-V MOSFET Series

Toshiba has developed the Gen-4 super-junction 600V and 650V DTMOS IV MOSFET series. Fabricated using the state-of-the-art single epitaxial process, DTMOS IV provides a 30% reduction in Ron*A, a figure of merit (FOM) for MOSFETs, compared to its predecessor, DTMOS III.  A reduction in Ron*A leads to smaller RDSon chips in the same packages.  This helps users to improve efficiency and reduce the size of power systems.

DTMOS IV, Super Junction Power MOSFETs

• Chips with optimized Rds(on)  x Qg
• Cgd and Rg allow easy control of switching performance
• Low C oss for optimized SPS operation also at light load (see diagram below)
• Lower temperature impact on Rds(on) (see diagram below)
• Best in class Rds(on) at TO-220SIS (FL): 600V, 0,065Ohm

As a result you get a high efficiently switching product at an excellent cost performance ratio.  Discover more in our DTMOS flyer (pdf 280KB)

Product Lineup

DTMOS IV 600V Standard "W" Series

	DPAK	IPAK	D2-PAK	I2-PAK	DFN	TO-220	TO-220SIS	TO-247	TO-3P(N)	TO-3P(L)
Package details
0.9Ω	TK5P60W	TK5Q60W					TK5A60W
0.75Ω	TK6P60W (0.82Ω)	TK6Q60W (0.82Ω)					TK6A60W
0.60Ω	TK7P60W	TK7Q60W					TK7A60W
0.50Ω	TK8P60W	TK8Q60W					TK8A60W
0.38Ω	TK10P60W (0.43Ω)	TK10Q60W (0.43Ω)			TK10V60W	TK10E60W	TK10A60W
0.30Ω	TK12P60W (0.34Ω)	TK12Q60W (0.34Ω)			TK12V60W	TK12E60W	TK12A60W		TK12J60W
0.19Ω			TK16G60W	TK16C60W	TK16V60W	TK16E60W	TK16A60W	TK16N60W	TK16J60W
0.15Ω			TK20G60W	TK20C60W	TK20V60W (0.17Ω)	TK20E60W	TK20A60W	TK20N60W	TK20J60W
88mΩ					TK31V60W (0.098mΩ)	TK31E60W	TK31A60W	TK31N60W	TK31J60W
65mΩ							TK39A60W	TK39N60W	TK39J60W
40mΩ								TK62N60W	TK62J60W
18mΩ										TK100L60W

DTMOS IV 600V FAST DIODE TYPE “W5”-SERIES

* : Mass production: Q2/2014
**: Mass production: 2014

DTMOS IV 600V HIGH SPEED TYPE (LOW Qgd) “X”-SERIES

* : Mass production: Q2/2014

Lower increase in on-resistance at high temperatures due to the use of a single epitaxial process
